MA180023
Módulo Insertable, Muestra de MCU PIC18F87J11 de 44 Pines, Se Conecta a Base de Procesador Principal
La imagen solo tiene fines ilustrativos. Consulte la descripción del producto.
- Fabricante:
- MICROCHIP MICROCHIP
- No. Parte Fabricante:
- MA180023
- No. Parte Newark
- 14R8813
- Hoja de datos técnicos:
- MA180023 Ficha de datos
Información del producto
¿Quiere ver productos similares? Simplemente seleccione los atributos requeridos y presione el botón ×
- :
- Microchip
- :
- PIC
- :
- PIC18
- :
- PIC18F
- :
- PIC18FxxJxx
- :
- Tarjeta Explorer PIC18 PICDEM
- :
- Muestra de MCU PIC18F87J11 de 44 Pines Módulo Insertable
- :
- -
Documentos técnicos (6)
Descarga de CAD
--Seleccione...
✔
--Seleccione...
×
Términos y condiciones
CAD Models - Notice
CAD Models and drawings are provided to you on a revocable limited licence for your internal use only but remain the property of the manufacturer who retain all intellectual property rights and ownership. They are provided to assist you in decision making and as design guide but are not guaranteed to be error free, accurate or up to date and is not intended to be taken as advice.
Use of these CAD models and other options provided are downloaded and used entirely at your own risk and by continuing you confirm acceptance of the above.
Resumen del producto
The MA180023 is a Plug-In module (PIM) with a 44-pin PIC18F46J11 that can be plugged into the PIC18 explorer board (DM183032). The PIC18F46J11 Plug-in module (PIM) is a accessory to the PICDEM PIC18 explorer board that allows users to easily experiment with the PIC18F46J11 family of microcontrollers. PIC18F46J11 is the superset member of the family and this PIM can be used to evaluate and develop with the PIC18F46J11, PIC18F45J11, PIC18F44J11, PIC18F26J11, PIC18F25J11 and PIC18F24J11 products. The PIM takes the place of the on-board PIC18F8722 device and changes the output of the voltage regulator on the board to the proper voltage level for these parts. This enables users to quickly evaluate the new PIC18FJ flash devices without having to buy a completely new demo board.
- Featuring NanoWatt XLP technology ideal for battery applications
- 13nA deep sleep mode, 54nA sleep mode
- 830nA real time clock & calendar operation in sleep modes
- 820nA watch dog timer operation in sleep modes
- Peripheral pin select for mapping Digital peripherals to various I/O for design flexibility
- Hardware RTCC provides clock, calendar & alarm functions
- Charge time measurement unit (CTMU) supports capacitive touch screens
- Two enhanced capture/compare/PWM modules
- Two MSSP serial ports for SPI with DMA or I2C communication
- 8bit parallel port, Dual Analogue comparators, 13 channel, 10bit ADC
Aplicaciones
Electrónica de Consumo, Industrial, Hospitalario, Automoción, Comunicaciones y Red
