5-1718321-3
Automotive Connector Contact, MCP 2.8 Series, Socket, Crimp
Image is for illustrative purposes only. Please refer to product description.
ManufacturerTE CONNECTIVITY - AMP
Manufacturer Part No5-1718321-3Copy
Manufacturer Standard Lead Time16 weeks
Newark Part No.53Y3631
Product RangeMCP 2.8
Your Part Number
1,965 In Stock
Need more?
Delivery in 4-6 Business Days(UK stock)
Order before 8pm EST standard shipping
| Quantity | Price |
|---|---|
| 1+ | $14.220 |
| 5+ | $12.930 |
| 10+ | $11.630 |
| 25+ | $11.150 |
| 50+ | $10.590 |
| 100+ | $10.250 |
| 250+ | $9.910 |
Price for:Each
Minimum: 1
Multiple: 1
$14.22
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
ManufacturerTE CONNECTIVITY - AMP
Manufacturer Part No5-1718321-3Copy
Manufacturer Standard Lead Time16 weeks
Newark Part No.53Y3631
Product RangeMCP 2.8
Technical Datasheet
Product RangeMCP 2.8
Contact GenderSocket
No. of Positions39Positions
Contact Termination TypeCrimp
Wire Size AWG Max-
Connector Body MaterialPBT (Polybutylene Terephthalate), Glass Filled Body
Wire Size AWG Min-
IP Rating-
IP Rating-
For Use WithAMP MCP 2.8 Series Power Contacts
Contact Material-
Voltage Rating36VDC
Current Rating32A
Contact Plating-
SVHCNo SVHC (04-Feb-2026)
Product Overview
5-1718321-3 is a 39 position, sealed, triple row, receptacle (female) LEAVYSEAL housing.
- Crimp termination
- Keyed mating alignment with strain relief
- Green colour Polybutylene Terephthalate (PBT) GF20 housing
- IP67, IP69K ingress protection and UL 94V-0 flammability rating
- 36VDC voltage rating
- 40A contact current rating and 2.8mm contact size
- Right angle mounting
- Operating temperature range from - 40 to 120°C
Technical Specifications
Product Range
MCP 2.8
Contact Gender
Socket
Contact Termination Type
Crimp
Connector Body Material
PBT (Polybutylene Terephthalate), Glass Filled Body
IP Rating
-
For Use With
AMP MCP 2.8 Series Power Contacts
Voltage Rating
36VDC
Contact Plating
-
Gender
Receptacle
No. of Positions
39Positions
Wire Size AWG Max
-
Wire Size AWG Min
-
IP Rating
-
Contact Material
-
Current Rating
32A
SVHC
No SVHC (04-Feb-2026)
Alternatives for 5-1718321-3
2 Products Found
Associated Products
4 Products Found
Legislation and Environmental
US ECCN:EAR99
EU ECCN:Unknown
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (04-Feb-2026)
