STM3210E-SK
IAR Starter Kit for STM32 F1 Series Performance and Access Line MCU's (STM32F103ZE MCU)
- Manufacturer:
- EMBEST EMBEST
- Manufacturer Part No:
- STM3210E-SK
- Newark Part No.:
- 63R5736
- Technical Datasheet:
- STM3210E-SK Datasheet
Product Information
Want to see similar products? Simply select your required attributes below and hit the button ×
- :
- STMicroelectronics
- :
- 32bit
- :
- STM32F1xx
- :
- ARM
- :
- Cortex-M3
- :
- STM32
- :
- STM3210E ARM-CM3 Board, LCD Panel, Emlink for ARMJTAG20-14-8 Convert Module, Various Cables, CDROM
- :
- -
Technical Documents (4)
CAD Downloads
--Please select...
✔
--Please select...
×
Terms and Conditions
CAD Models - Notice
CAD Models and drawings are provided to you on a revocable limited licence for your internal use only but remain the property of the manufacturer who retain all intellectual property rights and ownership. They are provided to assist you in decision making and as design guide but are not guaranteed to be error free, accurate or up to date and is not intended to be taken as advice.
Use of these CAD models and other options provided are downloaded and used entirely at your own risk and by continuing you confirm acceptance of the above.
Product Overview
STM3210E-SK is the low cost development kit for STM32F103ZE (72MHz, the very popular ARM Cortex-M3 processor) including the STM32F103ZE evaluation-board (STM3210E board)(SZE1) and Emlink for ARM(EAH1) JTAG adapter, so the developers can easy start to learn and test all the relevant applications on it, or evaluate new project design through this entire system.
- ST STM3210E ARM Cortex-M3 board
- Keil MDK-ARM development kit, 32K evaluation edition
- Emlink for ARM - a high speed JTAG emulator for ARM Cortex-M3 processors
- Plenty of example programs, all in source code
- Contains all necessary hardware & software which allows user to design, develop, integrate and test
- Emlink for ARM supports hardware and software breakpoints
- Keil MDK-ARM Development Kit is a μVision IDE, debugger and simulation environment
- Include one 2.4" TFT LCD (240*320)
- Contains CAN, USB device, TFTLCD, MicroSD card and 20pins JTAG interface
- Includes one RTC Unit with backup battery, temperature sensor
Applications
Communications & Networking, Motor Drive & Control, Medical, Industrial
Contents
One STM3210E ARM-CM3 Board, One RS-232 Serial Cable, One USB Cable, One 2.4" TFT LCD Panel (240x320), One Emlink for ARM
