TEXAS INSTRUMENTS  CD4066BE  Analog Switch, Quad Channel, SPST, 4 Channels, 240 ohm, 3V to 18V, DIP, 14 Pins

TEXAS INSTRUMENTS CD4066BE
TEXAS INSTRUMENTS CD4066BE
Technical Data Sheet (10.01KB) EN See all Technical Docs

Image is for illustrative purposes only. Please refer to product description.

TEXAS INSTRUMENTS CD4066BE
TEXAS INSTRUMENTS CD4066BE

Product Overview

The CD4066BE is a CMOS quad bilateral switch in 14 pin DIP package. This switch is intended for transmission or multiplexing of analogue or digital signals. It is pin to pin compatible with CD4016B but exhibits much lower on state resistance. The on state resistance is relatively constant over full input signal range. The CD4066B consists of four bilateral switches with independent controls. Both P and N device in given switch are biased on or off simultaneously by control signal. The advantages over single channel switches include peak input signal voltage swings equal to full supply voltage and more constant on state impedance over input signal range.
  • 15V digital or ±7.5V peak to peak switching
  • 125ohm typical on state resistance for 15V operation
  • Switch on state resistance matched to within 5 over 15V signal input range
  • On state resistance flat over full peak to peak signal range
  • Meets all requirements of JEDEC tentative standard JESD 13B
  • 5V, 10V and 15V parametric ratings
  • Matched control input to signal output capacitance reduces output signal transients
  • Supply voltage range from 3V to 18V
  • Operating temperature range from -55°C to 125°C



Product Information

Analog Switch Type:
SPST
No. of Channels:
4Channels
On State Resistance Max:
240ohm
Supply Voltage Range:
3V to 18V
Analog Switch Case:
DIP
No. of Pins:
14Pins
Operating Temperature Min:
-55°C
Operating Temperature Max:
125°C
Packaging:
Each
Product Range:
CD4000 LOGIC Series
Bandwidth:
40 MHz
MSL:
-
Turn On Time:
30 µs
Analog Switch Case Style:
DIP
SVHC:
No SVHC (15-Jun-2015)

Find similar products  grouped by common attribute

Applications

  • Signal Processing;
  • Communications & Networking

Legislation and Environmental

Moisture Sensitivity Level:
-
Product Traceability
RoHS Compliant:
Yes
