OSRAM  SFH4550  Infrared Emitter, High Power, 100 mA, 12 ns, 12 ns, 3 °, 1.5 V, -40 °C

OSRAM SFH4550

Image is for illustrative purposes only. Please refer to product description.

  • Manufacturer:
  • Newark Part No.: 97M1059
  • Manufacturer Part No SFH4550

Product Overview


The SFH4550 from Osram is a radial leaded high power infrared emitter. This device is used for infrared Illumination for cameras, sensor technology and data transmission.
  • Standard diode case style of T-1 3/4 (5mm)
  • Narrow emission angle of ±3°
  • Very high radiant intensity
  • Forward current If of 100mA
  • Wavelength at peak emission is 860nm
  • Forward voltage of 1.5V at IF = 100mA
  • Switching time of 12ns
  • Power dissipation of 180mW
  • Operating temperature range of -40°C to 100°C

Applications

Consumer Electronics; Portable Devices
Products which incorporate these devices have to follow the safety precautions given in IEC 60825-1 and IEC 62471.
Back to top

Product Information


  • Viewing Angle
  • Diode Case Style T-1 3/4 (5mm)
  • Forward Current If(AV) 100mA
  • Forward Voltage VF Max 1.5V
  • Rise Time 12ns
  • Fall Time tf 12ns
  • Operating Temperature Min -40°C
  • Operating Temperature Max 100°C
  • Packaging Cut Tape
  • Product Range -
  • Peak Wavelength 860 nm
  • No. of Pins 2
  • Radiant Intensity 700 mW/Sr
  • MSL -
  • Supply Voltage Range 1.5V
  • SVHC To Be Advised
