NEUTRIK  NC3MX  XLR Audio Connector, 3 Contacts, Plug, Cable Mount, Silver Plated Contacts, Metal Body, X Series

NEUTRIK NC3MX
NEUTRIK NC3MX
Technical Data Sheet (5.32MB) EN See all Technical Docs

The actual product may differ from image shown

NEUTRIK NC3MX
NEUTRIK NC3MX

Product Overview

The NC3MX from Neutrik is a 3 pole male XLR cable connector. This connector has a compact design with sturdy, rugged zinc die-cast shell for long lasting and durability and fibreglass reinforced hard plastic insert, chuck type strain relief for secure clamping of all cables.
  • Polyamide (PA 6.6 30 % GR) insert, brass (CuZn39Pb3) contact with silver plating
  • Zinc die-cast (ZnAl4Cu1) shell with nickel plating, polyacetal (POM) strain relief
  • Boot (polyurethan) with rubber gland gives high protection to cable bending stresses
  • Dielectric strength of 1.5KVDC
  • 16A rated current per contact and rated voltage < 50V
  • Lifetime > 1000 mating cycles
  • Maximum wire size of 14AWG (2.5 mm²)
  • UL ECBT2.E135070 certified
  • Flammability rating meets UL 94 HB and IEC 61076-2-103 standard compliance, IP 40 protection class
  • Temperature range from -30°C to +80°C



Product Information

No. of Contacts:
3Contacts
Gender:
Plug
Connector Mounting:
Cable Mount
Contact Plating:
Silver Plated Contacts
Connector Body Material:
Metal Body
Product Range:
X Series
Series:
X
Connector Type:
XLR
SVHC:
No SVHC (17-Dec-2015)
Connector Colour:
Silver

Find similar products  grouped by common attribute

Applications

  • Audio;
  • Consumer Electronics

Legislation and Environmental

Product Traceability
RoHS Compliant:
Yes
