MULTICOMP  5501-09PA-02-F1  Standard D Sub Connector, 5501 Series, DE, Plug, 9 Contacts, Solder

MULTICOMP 5501-09PA-02-F1

Image is for illustrative purposes only. Please refer to product description.

Additional images

  • Manufacturer:
  • Newark Part No.: 93K4290
  • Manufacturer Part No 5501-09PA-02-F1

Product Overview


The 5501 series from Multicomp are male and female type D sub connectors.
  • Current rating of 3A
  • Voltage rating of 250VAC/DC
  • Operating temperature range from -40°C to 85°C
  • Contact material is copper alloy
  • Selective gold plated contacts
  • Number of contacts varies from 9 to 50 pins
  • Maximum contact resistance of 30mohm
  • Minimum insulation resistance of 5000Mohm

Applications

Industrial

Product Range

Back to top

Product Information


  • Connector Type
  • Product Range 5501 Series
  • D Sub Shell Size DE
  • Gender Plug
  • No. of Contacts 9Contacts
  • Connector Body Material -
  • Connector Mounting
  • Contact Termination Type Solder
  • Contact Plating -
  • Contact Termination Solder
  • Series 5501
  • Contact Material -
  • SVHC To Be Advised

Availability

Availability:  1,242


  • 1,242 in stock for same day shipping

Check stock and lead times
    More stock available week commencing 6/13/16

Price for: Each

Minimum order quantity: 1

Order multiple quantity: 1

Price: $0.412 $0.412

Buy

Price

Quantity List Price
1 - 249 $0.412
250 - 499 $0.311
500 - 999 $0.278
1000 - 4999 $0.249
5000+ $0.227


Low

Legislation and Environmental


Back to top

Similar Products

Find products functionally similar to this one. Select one of the following links, and you will be taken to a product group page that presents all products in this category that share the given attribute.

Customer Reviews


Customer Q&A Exchange

(There is 1 question : 1 answer on this product)

Product Q&A

Ask your questions. Share your answers.



Browse Q&A


Search Questions
Need Product Support?
If you need immediate technical support use Live Support or Contact Us.
This space is yours...
Use this space to Ask your peers product questions or Answer those questions posted by them.
Details:
Looking for a backshell which can be used for 9 way D sub plug (part number 5501-09PA-02-F1).
3 years, 4 months ago
by
NewarkTechSupp
0points
0out of 0found this question helpful.
Was this helpful?(0)(0)

Answers

A:
Suggested part number of backshell which can be used with this dsub receptacle is MHDM-9-K from MH Connectors.
3 years, 4 months ago
by
NewarkTechSupport
0points
0out of 0found this answer helpful.
Was this helpful?(0)(0)
