UC232R-10 -

Cable, USB to RS232, For FT232Rl, 100mm

FTDI UC232R-10
FTDI UC232R-10

The actual product may differ from image shown

Manufacturer:
FTDI FTDI
Manufacturer Part No:
UC232R-10
Newark Part No.:
14N9613
Technical Datasheet:
(EN)
See all Technical Docs

Product Information

:
USB to RS232 Converter
:
230Kbaud
:
D Sub 9 Position Plug
:
FT232R
:
102mm
:
4"
:
-
Find similar products Choose and modify the attributes above to find similar products.

Product Overview

UC232R-10 ChiPi is the economy version of USB to RS232 converter cable range. It also serves as an evaluation cable for the FT232R. It utilises the minimum number of components required for a basic USB to RS232 converter designed using the FT232RL. Using the FT232R chip combined with an RS232 level converter and a few capacitors, the UC232R-10 ChiPi is a CE and FCC approved product which is one of the simplest USB to RS232 solutions around. Using a standard DB9 connector and powered from the USB port, the UC232R-10 ChiPi converter can be used with FTDI's VCP drivers to provide a COM port on a PC which is capable of communication rates with RS232 devices from 300baud up to 230kBaud. This version of the UC232R-10 is supplied with a nicely sculpted matte white plastic enclosure fitted, which covers the electronics inside. A 10cm USB cable is fitted.
  • FT232RL provides single chip USB to asynchronous serial data transfer interface
  • Entire USB protocol handled on the FT232RL chip. No USB specific firmware programming required
  • Fully assisted hardware or X-On / X-Off software handshaking
  • Royalty free VCP and D2XX drivers eliminate the requirement for USB driver development in most cases
  • Converter cable supply voltage comes from VCC, no external supply required
  • FT232RL has integrated USB resistors
  • USB bulk transfer mode
  • Low USB bandwidth consumption
  • UHCI / OHCI / EHCI host controller compatible
  • USB 2.0 full speed compatible

Applications

Communications & Networking, Audio, Imaging, Video & Vision, Sensing & Instrumentation, Industrial, Consumer Electronics, Wireless

Substitutes

Compare Selected
Manufacturer Part Number
Newark Part No.
Manufacturer / Description
Avail
Price For
Quantity

Associated Products

Compare Selected

Related Searches

US continental orders over $49 and under 50 pounds may qualify for free ground shipping. Click the link for the full Terms and Conditions of the offer.

982 In stock

for same day shipping

see cut-off times

Check stock and lead times
More stock available week commencing 9/4/17
$20.98 $ 20.98
Price for:
Each
Multiple: 1 Minimum: 1
Quantity Price
1 + $20.98
5 + $20.21
10 + $19.47
25 + $18.81
50 + $18.21
100 + $17.86
250 + $17.55
No longer stocked:: No Longer Manufactured::
Add to Cart
Total Price:
Total Price: ( )
Total Price: --

Customer Reviews

FTDI - UC232R-10 - USB TO RS232 CONVERTER CABLE 4.5 5 4 4
Good serial converter We use this product as a OEM in one of our products that we sell and since we started using it we have had no problems with them. I would recommend it, February 11, 2015
Does what it's supposed to Worked as advertised, and drivers are readily available at the supplier website if not already in your version of OS updates (one of my computers already had the driver, and had to go find the driver and install it on the other one). February 2, 2015
FTDI USB TO RS232 CONVERTER CABLE This product work as expected. The instructions do not have a accurate link to the driver download and the site was somewhat difficult to navigate to find the correct driver to download. Once this was accomplished everything worked well. April 10, 2014
Great Product We use this product for a specific software product that our clients use. If you use any other USB - Serial Adapter the printer will print and then the software locks up. We have tried more than 10 different brands and they all use a different (Less Expensive) USB - Serial controller. The FTDI controller chip is reliable and works flawlessly every time! If your looking for a solution that woks every time and does not require you to support it, this is the adapter to use. November 28, 2012
  • 2015-06-11T15:21:56.113-05:00
  • bvseo_lps, prod_bvrr, vn_prr_5.6
  • cp-1, bvpage1
  • co_hasreviews, tv_4, tr_4
  • loc_en_US, sid_14N9613, prod, sort_default
1-4 of 4

Customer Q&A Exchange

(There is 1 question : 1 answer on this product)

Product Q&A

Ask your questions. Share your answers.



Browse Q&A


Search Questions
Need Product Support?
If you need immediate technical support use Live Support or Contact Us.
This space is yours...
Use this space to Ask your peers product questions or Answer those questions posted by them.

Q:
1 answer

Drivers

Details:
I purchased this and it wants me to install drivers for it? I didn't receive any drivers or software for it.
1 year, 8 months ago
by
rwestfall
0points
0out of 0found this question helpful.
Was this helpful?(0)(0)

Answers

A:
You can download the driver for this cable from below supplier website:

http://www.ftdichip.com/Products/Cables/USBRS232.htm
http://www.ftdichip.com/Drivers/VCP.htm
http://www.ftdichip.com/Drivers/D2XX.htm
1 year, 8 months ago
by
TechGTC
0points
0out of 0found this answer helpful.
Was this helpful?(0)(0)
