NXP  TRK-USB-MPC5602P  MPC5602P, STARTERTRAK, MINI USB, OSBDM, DEV KIT

NXP TRK-USB-MPC5602P

Image is for illustrative purposes only. Please refer to product description.

  • Manufacturer:
  • Newark Part No.: 75T8383
  • Manufacturer Part No TRK-USB-MPC5602P

Product Overview


The TRK-USB-MPC5602P is a StarterTRAK USB development kit for MPC5602P 32bit Qorivva microcontroller. The Qorivva MPC5602P 32bit microcontroller (MCU) includes the latest in integrated devices for sophisticated chassis applications. These scalable power architecture devices are supported by an enablement ecosystem that includes software drivers, operating systems and configuration code to help you quickly implement your designs. The Embedded OSJTAG circuitry on the TRK-USB-MPC5602P board allows the processor on the board to be debugged and programmed via USB from a PC. In addition, the demo board can be powered using the USB bus.
  • Three user programmable multi coloured LEDs
  • Two user programmable push buttons
  • Temperature sensor
  • Primary tower system connector
  • OSBDM debugger through USB
  • 14 pin JTAG connection port
  • 14 pin JTAG connection port
  • Embedded OSJTAG

Applications

Automotive; Automotive
ESD sensitive device, take proper precaution while handling the device.

Contents

TRK-USB-MPC5602P board, Warranty card.
The board’s embedded OSJTAG is intended to function with the onboard processor only. It cannot be used to communicate with other devices.
Back to top

Product Specifications, Documents & More


  • Core Architecture: Power Architecture
  • Core Sub-Architecture: Power Architecture
  • Features: Modular Form Factor, USB, 32-bit MCU, Tower System Compatible
  • Kit Contents: Board only
  • No. of Bits: 32bit
  • SVHC: No SVHC (15-Jun-2015)
  • Silicon Core Number: MPC5xxx
  • Silicon Family Name: Qorivva
  • Silicon Manufacturer: NXP

Find similar products  grouped by common attribute

This product also features on the following pages and catalog editions:

  •  /
  •  131/61

Availability

Availability:  0

    More stock available week commencing 5/16/16

Non-Cancelable / Non Returnable

Price for: Each 1

Minimum order quantity: 1

Order multiple quantity: 1

Price: $25.00 $25

Buy

Price

Quantity List Price
1+ $25.00


Low

Legislation and Environmental


Back to top

Similar Products


Find products functionally similar to this one. Select one of the following links, and you will be taken to a product group page that presents all products in this category that share the given attribute.

Back to top
Back to top

Customer Reviews


Customer Q&A Exchange


(There is 1 question : 1 answer on this product)

Product Q&A

Ask your questions. Share your answers.



Browse Q&A


Search Questions
Need Product Support?
If you need immediate technical support use Live Support or Contact Us.
This space is yours...
Use this space to Ask your peers product questions or Answer those questions posted by them.
Details:
Please could you provide more information on TRK-USB-MPC5602P Product ?
2 years, 8 months ago
by
NewarkProductEnrichment01
0points
0out of 0found this question helpful.
Was this helpful?(0)(0)

Answers

A:
Description:
The TRK-USB-MPC5602P is a StarterTRAK mini USB development system. Freescale's StarterTRAK mini USB kit (TRK-USB-MPC5602P) is designed for you to easily and inexpensively give Freescale's 32bit Qorivva microcontrollers a test drive. Along with the on-board MPC5602P Qorivva MCU, it features a PCI card-edge for compatibility with the Freescale tower system, which means you can create your own custom development system based on your design needs. The Qorivva MPC560xP family of 32bit microcontrollers (MCUs) includes the latest integrated devices for sophisticated chassis applications. These scalable power architecture devices are supported by an enablement ecosystem that includes software drivers, operating systems and configuration code to help you quickly implement your designs.

Feature & Benefits:
MPC5602P microcontroller in a 100LQFP package
Three user programmable multi-colored LEDs
Two user programmable push buttons
Temperature sensor
Primary tower system connector
OSBDM debugger through USB
14 pin JTAG connection port
Embedded OSJTAG

Applications: Security, Automotive

Kit Contents:
TRK-USB-MPC5602P board, Freescale warranty card
